Deploying a Production-Ready VLLM Stack on Kubernetes with HPA Autoscaling

Author: Shivank Chaudhary

Published: November 1, 2025

alt text

Running large language models (LLMs) in production requires careful orchestration of resources, efficient scaling mechanisms, and robust infrastructure. In this guide, I’ll walk you through deploying a multi-model VLLM (Very Large Language Model) stack on Kubernetes with Horizontal Pod Autoscaling (HPA), based on our battle-tested production configuration.

This setup has been successfully managing multiple LLMs from OpenAI, Meta, Qwen, and Google, serving production traffic with automatic scaling based on demand.

Why VLLM?

VLLM is a fast and memory-efficient inference engine designed specifically for LLMs. It provides:

  • High throughput serving with PagedAttention

  • Continuous batching of incoming requests

  • Optimized CUDA kernels for better GPU utilization

  • OpenAI-compatible API endpoints

Architecture Overview

Our production stack consists of three key components:

  • Multiple Model Deployments: Each LLM runs in its own deployment with dedicated resources and configuration tailored to the model’s requirements.

  • Router Service: A lightweight router that distributes incoming requests across model instances and handles load balancing.

  • Autoscaling Infrastructure: HPA configuration that scales deployments based on custom Prometheus metrics, specifically monitoring the number of waiting requests.

Prerequisites

Before diving into the deployment, ensure you have:

  • A Kubernetes cluster with GPU nodes

  • Helm 3.x installed

  • Prometheus operator for custom metrics (required for HPA)

  • A storage class that supports ReadWriteMany (RWX) access mode

  • Hugging Face tokens for model downloads

Installation Guide

Step 1: Add the Repository

helm repo add vllm https://vllm-project.github.io/production-stack

Step 2: Understanding the Configuration

Let me break down the key configuration parameters for each model:

- name: "gptoss-20b"
  repository: "vllm/vllm-openai" # VLLM image supporting your model
  tag: "latest"
  modelURL: "openai/gpt-oss-20b" # Hugging Face model identifier
  replicaCount: 1 # Minimum replicas
  requestCPU: 10
  requestMemory: "64Gi"
  requestGPU: 1
  pvcStorage: "250Gi"
  pvcAccessMode:
    - ReadWriteMany # Critical for fast scaling!

Important Note: Using ReadWriteMany (RWX) access mode is crucial when HPA is enabled. This allows multiple pods to mount the same persistent volume simultaneously, dramatically reducing scaling time since new pods don’t need to re-download the model weights.

Step 3: VLLM Configuration Deep Dive

Each model has specific VLLM runtime configurations:

vllmConfig:
  enableChunkedPrefill: false
  enablePrefixCaching: false
  dtype: "bfloat16"
  extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.8"]

Key Parameters:

  • dtype: Using bfloat16 provides a good balance between performance and memory usage

  • gpu-memory-utilization: Set to 0.8-0.85 to leave headroom for CUDA operations

  • tensorParallelSize: For larger models requiring multiple GPUs (e.g., 120B model uses 4 GPUs)

  • maxModelLen: Context window size, adjust based on your use case

Step 4: Autoscaling Configuration

Please refer to keda autoscaling guide for HPA:

https://docs.vllm.ai/projects/production-stack/en/latest/use_cases/autoscaling-keda.html

Production Model Examples

Small Model: Llama 3.1 8B Instruct

Ideal for cost-effective inference with good performance:

- name: "meta-llama-31-8b-instruct"
  repository: "vllm/vllm-openai"
  tag: "latest"
  modelURL: "meta-llama/Llama-3.1-8B-Instruct"
  replicaCount: 1
  requestCPU: 8
  requestMemory: "32Gi"
  requestGPU: 1
  pvcStorage: "100Gi"
  vllmConfig:
    maxModelLen: 80000
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.85"]

Large Model: GPT-OSS 120B

For high-quality outputs requiring significant compute:

- name: "gptoss-120b"
  repository: "vllm/vllm-openai"
  tag: "latest"
  modelURL: "openai/gpt-oss-120b"
  replicaCount: 1
  requestCPU: 16
  requestMemory: "128Gi"
  requestGPU: 4 # Multi-GPU setup
  pvcStorage: "600Gi"
  vllmConfig:
    tensorParallelSize: 4 # Parallel across 4 GPUs
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.85"]

Embedding Model: Qwen3 Embedding 8B

Perfect for semantic search and RAG applications:

- name: "qwen3-embedding-8b"
  repository: "vllm/vllm-openai"
  tag: "latest"
  modelURL: "Qwen/Qwen3-Embedding-8B"
  replicaCount: 1
  requestCPU: 16
  requestMemory: "64Gi"
  requestGPU: 1
  pvcStorage: "100Gi"
  vllmConfig:
    maxModelLen: 32768
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.85"]

Multimodal Model: Qwen3 Omni

Audio-visual-text multimodal model with custom CUDA image:

- name: "qwen3-omni"
  repository: "qwenllm/qwen3-omni" # Custom repository
  tag: "3-cu124" # CUDA 12.4 optimized
  modelURL: "Qwen/Qwen3-Omni-30B-A3B-Instruct"
  replicaCount: 1
  requestCPU: 24
  requestMemory: "128Gi"
  requestGPU: 1
  pvcStorage: "100Gi"
  vllmConfig:
    tensorParallelSize: 1
    maxModelLen: 32768 # 32768 for 1 GPU, 65536 for 4 GPUs
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.90"]

Reasoning Model: LLM360 K2-Think

Specialized for complex reasoning tasks:

- name: "llm360-k2-think"
  repository: "vllm/vllm-openai"
  tag: "v0.10.1.1" # Specific version for compatibility
  modelURL: "LLM360/K2-Think"
  replicaCount: 1
  requestCPU: 16
  requestMemory: "64Gi"
  requestGPU: 4
  pvcStorage: "100Gi"
  vllmConfig:
    tensorParallelSize: 4
    maxModelLen: 65536
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.85"]

Vision-Language Model: Qwen3 Thinking

Large-scale multimodal reasoning model:

- name: "qwen3-thinking"
  repository: "vllm/vllm-openai"
  tag: "latest"
  modelURL: "Qwen/Qwen3-VL-235B-A22B-Thinking"
  replicaCount: 1
  requestCPU: 32
  requestMemory: "256Gi"
  requestGPU: 4 # Requires 4 GPUs
  pvcStorage: "900Gi" # Large storage for weights
  vllmConfig:
    tensorParallelSize: 4
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.95"]

Vision-Language Model: Qwen3 Instruct

High-performance multimodal instruction-following model:

- name: "qwen3-instruct"
  repository: "vllm/vllm-openai"
  tag: "latest"
  modelURL: "Qwen/Qwen3-VL-235B-A22B-Instruct"
  replicaCount: 1
  requestCPU: 32
  requestMemory: "256Gi"
  requestGPU: 4
  pvcStorage: "800Gi"
  vllmConfig:
    tensorParallelSize: 4
    dtype: "bfloat16"
    extraArgs: ["--disable-log-requests", "--gpu-memory-utilization", "0.9"]

Router Configuration

The router handles incoming traffic and distributes it across model instances:

routerSpec:
  replicaCount: 1
  autoscaling:
    enabled: true
    minReplicas: 1
    maxReplicas: 10
    targetCPUUtilizationPercentage: 80
  resources:
    requests:
      cpu: 400m
      memory: 700Mi
    limits:
      memory: 700Mi

The router is lightweight and scales independently based on CPU utilization.

Deployment

Deploy the Stack

helm install vllm vllm -f prod-values.yaml -n vllm --install --create-namespace

Verify Deployment

Check your pods:

kubectl get pods -n vllm

Expected output:

NAME READY STATUS RESTARTS AGE
vllm-deployment-router-5bc8f96685-284m4 1/1 Running 0 8d
vllm-gemma-3-27b-it-deployment-vllm-9d9f8b554-cdlvj 1/1 Running 2 8d
vllm-gptoss-120b-deployment-vllm-d75bdcc7f-zprkb 1/1 Running 6 7d
vllm-qwen3-omni-deployment-vllm-85bfc6dfc7-jb59f 1/1 Running 0 26h

Check HPA status:

kubectl get hpa -n vllm

Expected output:

NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS
vllm-gptoss-120b-hpa Deployment/vllm-gptoss-120b-deployment-vllm 0/20 1 2 1
vllm-router-hpa Deployment/vllm-deployment-router cpu: 2%/80% 3 10 3

Best Practices and Lessons Learned

Storage Strategy

Always use ReadWriteMany (RWX) for model weights: This is perhaps the most critical optimization. When a new pod spins up during scaling, it can immediately access the pre-downloaded model weights. Without RWX, each pod would need to download 100GB+ of weights, adding 5–10 minutes to scaling time.

GPU Memory Utilization

Start with 0.8 (80%) GPU memory utilization and adjust based on OOM errors. Larger models can often push to 0.85, but leave some headroom.

Scaling Behavior

Our aggressive scale-up (0 second stabilization) combined with conservative scale-down (10 minutes) prevents request queuing during traffic spikes while avoiding unnecessary pod churn during temporary dips.

Model Selection

Choose your models wisely:

  • 8B models for cost-effective, high-throughput workloads

  • 27B models for balanced quality and performance

  • 120B+ models only when output quality justifies the cost

Resource Requests

Set realistic CPU and memory requests. Underprovisioning leads to OOMKills; overprovisioning wastes cluster resources.

Monitoring and Observability

Key metrics to watch:

  • vllm_num_requests_waiting: Primary scaling trigger

  • vllm_num_requests_running: Current load

  • GPU utilization: Should stay high but not maxed out

  • Time to scale: Monitor how long new pods take to become ready

Cost Optimization Tips

  1. Right-size your models: Don’t use a 120B model when an 8B model suffices

  2. Use spot instances: For non-critical workloads, GPU spot instances can save 60–80%

  3. Aggressive scale-to-zero: Consider scaling to zero replicas during off-peak hours

  4. Batch requests: VLLM’s continuous batching is most efficient with multiple concurrent requests

Conclusion

Running a production VLLM stack requires careful attention to resource allocation, storage configuration, and autoscaling policies. The configuration shared here has proven stable and cost-effective for serving multiple models under varying load conditions.

Key takeaways:

  • Use ReadWriteMany storage for fast scaling

  • Configure aggressive scale-up, conservative scale-down

  • Monitor the right metrics (waiting requests, not just CPU/memory)

  • Choose appropriate models for your use case

  • Leave GPU memory headroom for stability

This setup has been serving production traffic reliably for weeks, automatically handling traffic spikes and optimizing resource usage during quiet periods.

Next Steps

  • Implement request queuing and prioritization

  • Integrate with litellm for router optimization and token metering

  • Add model caching for frequently accessed weights

  • Set up comprehensive monitoring dashboards

  • Implement blue-green deployments for model updates

  • Explore multi-cluster deployments for high availability
